THE HANDS THAT MAKE THE WORLD GO ROUND.



Fiat Professional and Ducato were uniquely and ingeniously crafted
with those people in mind. The type of people who do things the
right way the first time, and want a vehicle that helps to get the job
done even easier.

MORE THAN RANGE

IT’S THE RIGHT FIT.

The Fiat Ducato is perfect for every worker or company no matter the size because it was made with one goal in mind: help you do your job better. Versatility is the driving force behind every workforce, and no one knows that better than Fiat Professional who has created a series of vehicles that are comfortable, capable and adapt to all of the challenges in a constantly evolving world. Equipped with all the space, configurations and efficiency you need, the Ducato is offering the vehicle you need to put you on the road to after sucess.

MORE THAN TECHNOLOGY

THE TOOLS YOU NEED.

Nowadays the tools you need for your job aren’t only the ones you find in your tool-kit. Ducato has all the technology options and comfort to make all your everyday tasks easier and more efficient. All these new and upgraded instruments are perfectly placed in an interior that features new rigid door panels with storage space for better durability and organization. Once again, Fiat Professional keeps you up to date with the latest tools to make your job easier and your day run more smoothly.

MORE THAN POWER

THE STRENGTH TO PUSH FORWARD.

Uphill, downhill, the city streets or wide-open highway; whatever road is in front of you, the Ducato’s engine (140hp at 3600 rpm, 320 nm at 1800rpm) has all the power and efficiency to get the job done. Ducato delivers advanced solutions for maximum power and minimum emissions.

MORE THAN SAFETY

KEEPING YOUR BUSINESS PROTECTED.

Whether you’re an artisan, construction worker, jack - of - all - trades or own a fleet, protection and security are the backbones of every business. Fiat Professional knows you take your job safety seriously and we want you to know that Ducato does the same too.

TYRE PRESSURE MONITORING SYSTEM

"Monitors tyre pressure constantly, and indicates any loss of pressure on the on-board display."

DOUBLE LEAF REAR SUSPENSION

The Load Adaptive Control integrated into the ESC detects vehicle load conditions, such as weight and centre of gravity. When these parameters change, it calculates new settings and cut-in thresholds and sends them to the ABS, ASR, ESC and Rollover Mitigation functions, so as to maximise their efficiency at all times.

BEST-IN-CLASS CARGO EFFICIENCY

"A work partner like no other, with up to 2t of playload and up to 17m3 of load space."

MORE THAN SPACE

THE RIGHT DIMENSIONS.

Ducato understands what you need and works to make your job easier. Choose the wheelbase that is the right size for you, so your goods and pallets will fit perfectly.

THE DAY HAS CLOSED, BUT THE FUTURE IS WIDE OPEN.

Privati
L2H2

MECHANICAL & PERFORMANCE

  • Minimum turning radius (m): 12.4
  • Wheel: 15" Steel
  • Tyres: 215/70 R15
  • Maximum speed km/h: 153

EXTERIORS

  • Wheelbase: 3450
  • Overall length: 5413
  • Overall height: 2,524
  • Maximum height of rear doors: 1,790

INTERIORS

  • Maximum load height: 1,932
  • Maximum load length: 3,120

CAPACITIES

  • Total Cargo Load Volume: (m3) 11.5
WEIGHTS
  • Kerb Weight (Kg): 2,015
  • Gross Weight (Kg): 3,510
  • Maximum Payload Capacity (Kg) (GVW - Kerb Weight): 1,495





L3H2

MECHANICAL

  • Engine: 2.2L MultiJet
  • Fuel System: Diesel
  • Displacement (cc): 2,184
  • Cylinders / Valves: 4
  • Bore (mm): 84
  • Stroke  (mm): 99
  • Power (hp): 140 hp / 3500
  • Torque (Nm): 350 Nm@ 1400
  • Transmission options: 6-speed manual
  • Brakes, front: Vented disc
  • Brakes, rear: Disc rotor
  • Brakes, parking: Manual

PERFORMANCE

  • Fuel consumption Extra Urban  (km/l ): 13.5
  • Fuel consumption Urban  (km/l): 9.1
  • Fuel consumption Combined  (km/l): 11.5
  • Average Fuel Autonomy (km): 1034
  • CO₂ emissions  (g/km): 229.92
  • Emission classification: Euro 5

EXTERIORS

  • Wheelbase: 4,035
  • Overall length: 5998
  • Body width, without / with mirrors: 2050 / 2485
  • Overall height: 2,524
  • Front track width: 1,810
  • Rear track width: 1,790
  • Maximum width of side doors: 1,250
  • Maximum height of side doors: 1,755
  • Maximum width of rear doors: 1,562
  • Maximum height of rear doors: 1,790
  • Minimum ground clearance: 144

INTERIORS

  • Maximum load height: 1,932
  • Maximum load length: 3,705
  • Maximum load width (With partitions/ With wheels arches): 1,861 / 1,418

CAPACITIES

  • Total Cargo Load Volume (m3): 13.0
  • Fuel tank capacity (L): 90L

WEIGHTS

  • Kerb Weight (Kg): 2,150
  • Gross Weight (Kg): 3,510
  • Maximum Payload Capacity (Kg) (GVW - Kerb Weight): 1,475





L4H3

MECHANICAL & PERFORMANCE

  • Minimum turning radius (m): 14.3
  • Wheel: 16" Steel
  • Tyres: 225/75 R16C
  • Maximum speed km/h: 143

EXTERIORS

  • Wheelbase: 4,035
  • Overall length: 6,363
  • Overall height : 2,764
  • Maximum height of rear doors: 2,030

INTERIORS

  • Maximum load height: 2172
  • Maximum load length: 4,070

CAPACITIES

  • Total Cargo Load Volume (m3): 17

WEIGHTS

  • Kerb Weight (Kg): 2,225
  • Gross Weight (Kg): 4,250
  • Maximum Payload Capacity (Kg) (GVW - Kerb Weight): 2,025
